The Perimeter Protocol: Distributing Points for Square Box Formations

In the realm of Real-Time Strategy (RTS) and tactical RPG development, managing how a group of entities occupies space is a fundamental challenge. While filling a solid square is straightforward, distributing units specifically along the perimeter—often referred to as a "hollow box" or "unit formation"—requires a more nuanced algorithmic approach. This technique is essential for creating defensive perimeters, surrounding an objective, or organizing a squad into a recognizable military-style formation. By mapping a single linear index to a 2D coordinate space along the edges of a box, developers can ensure perfectly equidistant spacing regardless of the number of units or the scale of the formation.

Table of Content

• Purpose: Tactical Spacing and Formation Logic
• The Logic: Mapping Linear Indices to Edges
• Step-by-Step: Implementing the Square Distribution
• Use Case: Defensive Squad Shielding
• Best Results: Handling Floating Point Precision
• FAQ
• Disclaimer

Purpose

Algorithmic perimeter distribution serves several critical functions in modern 2026 game engines:

• Unit Visibility: Ensures every unit in a formation has an unobstructed line of sight to the exterior.
• Collision Optimization: Prevents units from overlapping by calculating exact coordinates before they begin their pathfinding routine.
• Visual Order: Creates a clean, professional aesthetic for squad-based movement, essential for high-fidelity tactical simulations.

The Logic: Mapping Linear Indices to Edges

To distribute $N$ points on a square with side length $S$, we treat the total perimeter length ($P = 4 \times S$) as a continuous line. We then "bend" this line at the corners.

The algorithm calculates the distance between points as $d = P / N$. For any point $i$ (from $0$ to $N-1$), its distance along the perimeter is $D = i \times d$. We then determine which of the four sides the point falls on based on the current distance $D$ relative to $S$.

Step-by-Step

1. Define Formation Parameters

Determine the center of the formation $(cx, cy)$, the side length $S$, and the total number of points $N$.

2. Calculate the Normalized Position

For each point $i$, calculate a value $t$ that represents its progress around the perimeter from $0.0$ to $1.0$.

float t = (float)i / N;
float perimeterPos = t  4.0f; // Scale to 4 sides

3. Map to Coordinates

Using the perimeterPos, determine which side the unit belongs to and calculate local offsets from the center:

• Side 0 (Top): $x = -S/2 + (perimeterPos \times S)$, $y = S/2$
• Side 1 (Right): $x = S/2$, $y = S/2 - ((perimeterPos - 1) \times S)$
• Side 2 (Bottom): $x = S/2 - ((perimeterPos - 2) \times S)$, $y = -S/2$
• Side 3 (Left): $x = -S/2$, $y = -S/2 + ((perimeterPos - 3) \times S)$

4. Apply Global Offset

Add the center coordinates $(cx, cy)$ to the local $x$ and $y$ to place the point in world space.

Use Case

A developer is creating a "Boss Phase" where 12 minions spawn and must instantly surround the boss in a square protective formation.

• The Action: The script iterates from $i = 0$ to $11$.
• The Implementation: Using a side length of $10$ units, the algorithm assigns each minion to a specific coordinate on the perimeter.
• The Result: The minions move to their points, forming a perfect hollow square regardless of the boss's current position on the map.

Best Results

FAQ

What if $N$ is not divisible by 4?

The algorithm provided uses floating-point math to distribute points evenly along the distance, so it handles any $N$ perfectly. The points will not necessarily be at the corners, but they will be equidistant.

How do I rotate the square?

After calculating the local $(x, y)$, apply a rotation formula:
$newX = x \times \cos(\theta) - y \times \sin(\theta)$
$newY = x \times \sin(\theta) + y \times \cos(\theta)$

Is this efficient for 1000+ units?

Yes. Since there are no physics checks or complex iterations, this $O(N)$ calculation can be performed every frame if necessary, though caching the positions is recommended for static formations.

Disclaimer

This algorithm assumes a 2D Euclidean plane. If your game involves 3D terrain with varying heights, you must perform a "Raycast" or "Ground Snap" after calculating these 2D coordinates to ensure units are not floating or buried. This tutorial reflects 2026 game development standards and is intended for educational use. Mathematical accuracy is dependent on the floating-point precision of your chosen language (C#, C++, or Python). March 2026.
